Cisco Webex Board 55

Easy-to-use high-quality collaboration

Designed with you in mind

Nikmati pengalaman kolaborasi yang mudah digunakan, berbasis sentuhan, dan berkualitas tinggi. Cisco Webex Board mengintegrasikan alat paling umum yang dibutuhkan untuk kolaborasi tim di ruang pertemuan fisik menjadi satu perangkat elegan.

Connect virtual teams through the app

Anda dapat menyimpan semua yang Anda buat di Webex Board di cloud dan mengaitkannya dengan ruang virtual. Anggota tim dapat menggunakan aplikasi Tim Cisco Webex untuk mengetahui di mana mereka tinggalkan di ruang fisik dan terus bekerja di mana saja.

Virtual teams can collaborate anywhere

Webex Board anticipates the teams'

Intelligently anticipates your needs

Papan Webex secara otomatis bangun ketika Anda memasuki ruangan. Ini mendeteksi perangkat yang didukung aplikasi Tim Webex Anda dan menyarankan aktivitas, seperti panggilan, papan tulis, atau berbagi presentasi Anda secara nirkabel.

Technology for natural experiences

Kamera 4K yang kuat menangkap gambar resolusi tinggi, sudut lebar hampir seluruh ruangan. Array 12-mikrofon menghasilkan suara yang jernih, jernih, secara otomatis memperkuat dan memodulasi suara sehingga semua peserta rapat terdengar hebat.

Technology-enhanced audio and calling experience

Remote whiteboard collaboration is a breeze

Whiteboard with your entire team—local and remote

Buat papan tulis dengan mudah di Papan Webex atau melalui aplikasi Tim Webex. Nikmati papan tulis dua arah, cubit / perbesar dan banyak lagi.

Product Overview

Software

Cisco Webex Board OS, provisioned by the Cisco Webex in the cloud

Components

Fully integrated unit is delivered with:

  • Multi-touch 55-inch LED display
  • 4K camera
  • 12-microphone array
  • Speakers
  • White boarding pen

Display

  • Edge LED LCD – 55-inch 4K, 350 nits, 16:9
  • Viewing angle: +- 89 degrees (all directions)
  • Number of colors: 1.07 billion (10 bit)
  • Contrast: 1:4000
  • Response time: 5.5 ms

User interface

  • Capacitive touch
  • Protective glass with optical bonding
  • Multi-touch

Inputs and outputs

  • HDMI input
  • Home button
  • 3.5-mm mini jack audio out (line out)
  • Two USB 3.0 (for serviceability)

Camera overview

  • Fixed lens, infinite focus
  • F-value: 2.8
  • 4Kp60
  • Horizontal Field Of View (HFOV): 83 degrees
  • Vertical Field Of View (VFOV): 55 degrees
  • Camera mounted tilted: -25 degrees

Audio system

  • 12-element microphone array (with intelligent voice tracking)
  • Integrated voice-optimized speakers

Network

  • Ethernet (RJ-45) 100/1000 Mbps
  • Wi-Fi 802.11a/b/g/n; 802.11ac (2.4 and 5 GHz)
  • IPv4 Dynamic Host Configuration Protocol (DHCP)/static
  • Network Time Protocol (NTP)
  • HTTP Proxy support (for signaling, not media)

User controls

  • Control Cisco Webex Board directly from the touchscreen or using the Cisco Webex Teams app

Language support

  • English, Spanish, German, French, French Canadian, Portuguese, Japanese, Czech, Danish, Dutch, Norwegian, Swedish, Latin American Spanish, Italian, Finnish, Polish, Turkish
  • Additional languages to be supported in future software release

Physical dimensions (H x W x D)

  • 32 x 50 x 1.9 in

Weight

  • 87.7 lb (39.8 kg)

Physical dimensions and weight of packaging (H x W x D)

Main unit

  • Package size: 36.2 x 55.7 x 7.5 in (919 x 1416 x 191 mm)
  • Weight: 88 lb (39.8 kg)
  • Shipping weight (including packaging): 101 lb (45.8 kg)

Floor Stand (New Design)

  • Package size: 40.7 x 56.1 x 6.8 in (1034 x 1426 x 172 mm)
  • Weight: 34.8 lb (15.8 kg)
  • Shipping weight (including packaging): 48.3 lb (21.9 kg)

Wall Stand (New Design)

  • Package size: 36.8 x 51.6 x 4.7 in (934 x 1311 x 119 mm)
  • Weight: 30.9 lb (14 kg)
  • Shipping weight: 30.8 lb (14 kg)

Wall Mount Kit

  • Consolidated package size: 10 x 54.5 x 2 in (253 x 1386 x 51 mm)
  • Weight: 11 lb (5 kg)
  • Shipping weight: 13.2 lb (6 kg)

Cisco Webex Board and the selected mounting option will be shipped in a consolidation pack on a pallet. The dimensions above describe each of the individual boxes within the consolidation packaging.

Power

Autosensing power supply

100 to 240 VAC, 50 to 60 Hz

Power consumption:

  • Sleep: 45W
  • Idle or in-use: 185W

System management

Cisco Webex Board is managed in the administrator portal in Cisco Webex, giving system status and overview, activation, configuration, metrics, and troubleshooting.

Operating temperature and humidity

0° to 35°C (32° to 95°F) at relative humidity 10% to 90% (noncondensing)

Bandwidth requirements

Minimum bandwidth:

  • 720p30 from 768 Kbps
  • 1080p30 from 1.72 Mbps

Maximum bandwidth:

  • Transmit: 4.3 Mbps
  • Receive: 10 Mbps

Video inputs

  • 1 HDMI for local presentation or sharing in meetings Supports formats up to maximum 4K (3840 x 2160) Frame rate of 60 fps for up to 1080p and 30 fps for 2160p Extended Display Identification Data (EDID)

Presentation capabilities

Local presentation up to 4K; Audio over HDMI

Live video resolutions (encode/decode) – main video and presentation sharing

Main video:

  • Up to 1920 x 1080@30 (HD1080p)

Presentation sharing:

  • Up to 1920 x 1080@30 (HD1080p)

Audio features

  • High-quality 20-kHz audio
  • Acoustic echo cancellation
  • Automatic Gain Control (AGC)
  • Automatic noise reduction
  • Active lip synchronization
  • Microphone array with intelligent voice tracking capabilities
